| Place of Origin: | CHINA |
|---|---|
| Brand Name: | Welsonpower |
| Certification: | TUV(IEC 62619, IEC 62040 pending) |
| Model Number: | ES50000 |
| Minimum Order Quantity: | Negotiable |
| Price: | USD1000-USD1300/SET |
| Packaging Details: | Standard Export Package |
| Delivery Time: | 15-30 working dyas |
| Payment Terms: | L/C, T/T, D/A, D/P, Western Union, MoneyGram |
| Supply Ability: | 2000 sets per month |
| Cell Type: | Pouch 50AH | Continuous Current: | 60A |
|---|---|---|---|
| Chemistry Of Cell: | LiFePO₄ | Weight: | 48Kgs |
| Voltage: | 51.2V | Total Energy: | 5.1Kwh |
| High Light: | smart bms lifepo4 Home Battery,lifepo4 Home Battery Powerwall,lifepo4 Powerwall 10Kwh |
||
Residential Energy Storage Solution
Integrated with lithium-ion battery energy storage system and
home energy management system,the solution is expandable on
demand and has a variety of combinations.Flexible,efficient and
customized products and services,it is friendly to home users to
build a clean,independent and economic micro-grid.
|
Model
|
Uhome-LFP 2400M
|
Uhome-LFP 2500M
|
Uhome-LFP 4800M
|
Uhome-LFP 5000M
|
|
Total energy(DC)
|
2.4kWh
|
2.5kWh
|
4.8kWh
|
5.1kWh
|
|
Usable energy(DC)
|
2.2kWh
|
2.2kWh
|
4.3kWh
|
4.6kWh
|
|
Norminal dis-/charge power
|
1.5kw
|
1.5kw
|
2.88kw
|
3.0kw
|
|
Peak power(only discharge )
|
3.0kw for 3sec
|
3.0kw for 3sec
|
6.0kw for 3sec
|
6.0kw for 3sec
|
|
Constant current(only discharge )
|
40A
|
40A
|
70A
|
80A
|
|
Voltage
|
42-54Vdc
|
48-56Vdc
|
42-54Vdc
|
96-112Vdc
|
|
Norminal voltage
|
48Vdc
|
51.2Vdc
|
48Vdc
|
51.2Vdc
|
|
Norminal current
|
30A
|
30A
|
60A
|
60A
|
|
Max.charge voltage
|
53.75Vdc
|
53.75Vdc
|
53.75Vdc
|
57.6Vdc
|
|
Weight
|
25kg
|
27kg
|
44kg
|
45kg
|
|
Dimension(mm)
|
500*442*88mm
|
500*442*88mm
|
500*442*136mm
|
500*442*135mm
|
|
Max.recommended DOD
|
90%
|
|||
|
Operating condition
|
Indoor
|
|||
|
Operating temperature
|
charge
|
0-50ºC | ||
| discharge | -10-55ºC | |||
|
WIFI frequency range
|
2400MHz--2483MHz
|
|||
|
Humidity
|
<60%(No condensed water)
|
|||
|
Pollution degree
|
3
|
|||
|
Over voltage category
|
II
|
|||
|
Cooling type
|
Natural cooling
|
|||
|
Case material
|
Metal
|
|||
|
Color
|
Black or Grey
|
|||
|
Installation
|
Wall mounting / Ground Installation
|
|||
|
IP rating
|
IP20
|
|||
|
Protective class
|
I
|
|||
|
Max.number of parallel
|
16
|
|||
|
Warranty
|
10years
|
|||
|
Life span
|
>15years
|
|||
|
Communication
|
CAN/RS485
|
|||
|
Protection mode
|
Dual hardware protection
|
|||
|
Battery protection
|
Over-current/Over-voltage/Short circuit /Under voltage/Over temperature
|
|||
|
Safety
|
CE TUV
|
|||
|
Hazardous material classification
|
9
|
|||
|
Transportation
|
UN38.3
|
|||
Key Feature
>Digital Monitoring System APP
>High Inverter Compatibility
> Reliable LFP Cells
>CANbus Standard Connection
>Natural Cooling System
>Assemblly freely in parallell up
to 16P(48V326.4kWh)
>10 Years Limited Warranty
Communication compatible Inverter brand that have been tested and are supported
SOLIS GROWATT DEYE MEGAREVO LUXPOWER KEHUA SOFAR INVT,.. Etc.
WelsonPower 48V Lithium Battery System
| Brand | Hybrid Inverter | Battery Selection | AC coupled Inverter |
| Victron | Quattro48/5000/70 VE.Bus Firmware version:V 2.61 |
WelsonPower | Multiplus-‖48/3000/35 Firmware version:V 2.61 |
| LUXPOWER | LXP-(3-5)K hybrid | WelsonPower | LXP-3600ACS |
| SOLIS | RHI-(3-5)k-48ES RHI-(3~6)k-48ES-5G |
WelsonPower | RAI-3k-48ES-5G |
| SERMATEC | SMT-5K-TL-LV | General | |
| KEHUA | SPH3600-5000 | General | |
| SOFARSOLAR | HYD (3000-6000)-ES | General | ME3000 |
| GROWATT | SPH3000-6000 SPH5000 SPF5000ES SPF5000TL |
General | |
| INVT | BD (3-5) KTL BD (3-5) KTL-HS |
General | BD3k-PS |
| MEGAREVO | R3KL1~R5KL1 R3K6L1~R6KL1 |
General 48V or
51.2V |
|
| DEYE | SUN-(5~6)K-SG01LP1-US SUN-(7.6~8)K-SG01LP1-EU |
General | |
| Goodwe | GW3648-EM GW5000ES |
Default25Ah Default50Ah |
GW5000S-BP |
| AISWEI | POW-VM5K-III | ASW5000H-S | |
| Voltronic | L1b | ||
| SRNE | HF4850S80-145 | WelsonPower | |
| Schneider | Conext-XWpro 8548 | Be adjusting | |
| SMA | SUNNY ISLAND 4.4M / 6.0H / 8.0H | Be adjusting | |
| Senergy |
SE5000HB-1OO
|
WelsonPower |
| Brand |
Inverter type
|
Firmware Version
|
Battery selection
|
Note
|
| Solis |
RHI-3P(5-10)kW-HVES-5G
|
V04
|
WelsonP
|
|
| GoodWe |
GW10K-ET
|
030310
|
Default25Ah
Default50Ah
Default100Ah
|
Special BMS firmware
|
| MEGAREVO |
R(7~12)KH1
|
ARM V1.01.35
DSP V1.02.10
|
Genera
|
|
| Sunways |
STH 4~12KTL-HT
|
V1.00 |
WelsonPower
|
|
| SOFARSOLAR |
HYD 10KTL-3PH
HYD 20KTL-3PH
|
|
General
|
|
| Growatt |
SPH 10000TL3 BH
|
General
|
||
| SMA |
SBS5.0-10
|
Be adjusting
|
| Item | Data | Note | |||||
| Uhome-NCA 6.8kWh/LV |
Uhome-LFP 5.8kWh/LV |
Uhome-LFP 2400 |
Uhome-LFP
5000
|
Uhome-LFP
10kWh/LV
|
Uhome-LFP
12.5kWh/LV
|
||
| Max. Charge Current | 60A/0.5C | 57A/0.5C | 30A/0.5C |
60A/0.6C
|
90A/0.45C
|
120A/0.48C
|
|
| Max. Discharge Current | 60A/0.5C | 57A/0.5C | 30A/0.5C |
60A/0.6C
|
90A/0.45C
|
120A/0.48C
|
|
| Rate d Voltage | 48V | 48V | 51.2V |
51.2V
|
51.2V
|
51.2V
|
|
| Capacity | 131Ah | 120Ah | 50Ah |
100Ah
|
200Ah | 250Ah | |
| Over Charge Voltage | 58.0V | 51.7V | 57.6V |
57.6V
|
57.6V | 57.6V | |
| Low Voltage | 42V | 45.0V | 48.0V |
48.0V
|
48.0V | 48.0V | |
| Float charge voltage | 57.7V | 51.5V | 56.0V |
56.0V
|
56.0V | 56.0V | If needed |
| Over Temperature | 45ºC | 45ºC | 45ºC | 45ºC | 45ºC | 45ºC | |
| Low Temperature | -10ºC | 0 | 0 | 0 | 0 | 0 | |
| Constant Charge Voltage | 57.5V | 51.5V | 55.8V | 55.8V | 55.8V | 55.8V | |
| Discharge End Voltage | 43V | 45V | 48.0V | 48.0V | 48.0V | 48.0V | |
51.2V 5KWh Rechargeable 48V Powerwall Battery For Home Solar System
48V 51.2V 5KWh Powerwall Battery Rechargeable Li-ion Battery For Home Solar System
48V 100Ah 5KWH/48V200Ah 10KWH Powerwall Battery
Support parallels connection to max 200KWh.
5 years warranty and 10 years lifespan design.
OEM&ODM service and accept print your logo.
Easily installation and operation ,just plug and play.
More than 6000 times deep cycle as up to 90% DOD.
With intelligent BMS system to optimize the performance.
Compact design, LCD screen, convenient setting buttons and IP65.
Optional for LCD display and communication (CAN/RS485/RS232).
Max discharge current up to 150-200A, compatible with solar system.
Powerwall Battery Specification
| Nominal Voltage | 51.2V |
| Nominal Capacity | 100Ah |
| Energy | 5120Wh |
| Internal Resistance | ≤10mΩ |
| Cycle Life | >3000 cycles@1C 100% DOD |
| Months Self Discharge | <3% |
| Efficiency of Charge | 100%@0.5C |
| Efficiency of Discharge | 96-99% @1C |
| Charge Cut-off Voltage | 58.4±0.2V |
| Charge Mode | 0.2C to 58.4V, then 58.4V charge current to 0.02C(CC/CV) |
| Recommend Charge Current | 20A |
| Max. Charge Current | 100A |
| Max. Continuous Discharge Current | 100A |
| Max. Pulse Current | 200A(10S) |
| Discharge Cut-off Voltage | 40V |
| Charge Temperature | 0ºC to 45ºC(32F to 113F)@60±25% Relative Humidity |
| Discharge Temperature | -20ºC to 60ºC(-4F to 140F)@60±25% Relative Humidity |
| Storage Temperature | 0ºC to 40ºC(32F to 104F)@60±25% Relative Humidity |
| Water Dust Resistance | IP67 |
| Cell&Method | 16S |
| Package | Metal Case |
| Dimensions(in./mm.) | 780*634*114mm |
| Weight(lbs./kg.) | 68kg |
Home Powerwall Images
Compatible Inverter Brand
Elite powerwall are support communication with most inverter brands such as Deye, Growatt, Kstar, Victron, Goodwe.
Package: With high quality pearl wool, UN cartons / Plywood, plastic pallet.
Shipping: By air, by sea, by express, railway transportation and so on.
1. Professional technical team: WelsonPower’s R&D technical team has received more than 20 inventions and application patents.
2. Unique pack technique: WelsonPower possesses special pack technique to batter protect the battery cell and increase the life span of the battery pack.
3. Safety certification guarantee: Most batteries have been certificated according to international standard including CE, MSDS, UN38.3, UL etc..
4. Professional sales team: WelsonPower possess well-trained sale team that help clients addressing difficulty meeting during battery selecting and battery using.
5. Punctual delivery: WelsonPower has strict production plan to promise punctual delivery of the goods.
6. Perfect after-sales service: WelsonPower has a professional QC team which applies strict quality control on production and provide perfect after-sales service to clients.
1 good quality, experience with famous brands
2 OEM service for customized battery
3 26650 cell(2000 times cycle 3 life.after 2000 tims,still keeps 80%of inital capacity
4 Our certification is complete
5 Sample order(<10 pcs) is available---helps you test the quality with "O"risk
6 12 month wanrranty---replace one by one if there is any quality problem
7 In the field of batteries Have more than 10 year professional experience
With high quality pearl wool, UN cartons / Plywood, plastic pallet.
By air, by sea, by express, railway transportation and so on.
1. Shippment to USA:By sea+Express(DDP,Tax free)
ETD:5-8 days
ETA:25-35 days after sailing(This is the delivery time for most orders. Please wait patiently or contact us online)
The tracking will be updated after pick up by local express.Usually it will take around 15-25 days after sailing.
2. Shipment to EU:By railway+Express(DDP,Tax free).Except Switzerland,Romania
ETD:5-8 days
ETA:30-45 working days after shipping(This is the delivery time for most orders. Please wait patiently or contact us online)
The tracking will be updated after pick up by local express.Usually it will take around 25-40 working days after shipping.
3. We can't deliver the following address directly:
USA: Military address and PO box address are not acceptable;
Puerto Rico, Virgin Islands, Guam, Alaska Note: Hawaii does not include customs duties and requires additional freight, Please contact us online.
Portugal: Azores and Madeira
Spain:Canary Islands, hueda and melilia
Russia: Kamchatka Peninsula
Other:Some remote areas not listed,Please provide shipping address and zip code to to us to check.
