Ifr32650 Ifr32700 6ah 3.2V Lifepo4 Battery Bms Cylindrical LiFePO4 Cell

Basic Information
Place of Origin: China
Brand Name: Welsonpower
Certification: CE, UL, MSDS, UN38.3, MSDS
Model Number: 3.2V 1.5Ah
Minimum Order Quantity: 200pcs
Price: $0.59-1.99/PCS
Packaging Details: Carton box with pallet
Delivery Time: 30-45work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10000pcs per month
Model: LiFePO4 3.2V 1.5Ah Energy: 4.8Wh
Rated Voltage: 3.2V Rated Capacity: 1.5Ah
Application: ESS, EV, Solar System Cycle Span: 3000-5000 Cycles
Self-diacharge Rate: <3% Type: Cylindrical
High Light:

32700 lifepo4 battery cells

,

32650 lifepo4 cell

,

lifepo4 battery 3.2v Welson

BIS LiFePO4 Battery Cell

6000mAh LiFePO4 Battery Cell

BIS 32700 Lifepo4 Cells





BIS LiFePO4 Battery Cell



WelsonPower BIS Approved 3.2V 6Ah 6000mAh LiFePO4 Lithium Battery Cell



Product Description



Feature

1. Lighter weight with larger capacity compared with Lead-acid battery.

2. No toxic material contained,which is environmentally friendly.

3. Durable:With deep cycle, which can reach more than 3000 cycles.

4. Excellent performance under high temperature operationg situation.

5. Without memory effect, with high rentention rate and low-self discharge rate.



Nominal Voltage

3.2V

Nominal Capacity

6Ah

Energy

19.2Wh

Internal Resistance

≤10mΩ

Cycle Life

>3000 cycles@1C 100% DOD

Months Self Discharge

<3%

Efficiency of Charge

100%@0.5C

Efficiency of Discharge

96-99% @1C

Charge Cut-off Voltage

3.65±0.2V

Charge Mode

0.2C to 3.65V, then 3.65V charge current to 0.02C(CC/CV)

Recommend Charge Current

1.5A

Max. Charge Current

6A

Max. Continuous Discharge Current

6A

Max. Pulse Current

12A(10S)

Discharge Cut-off Voltage

2.5V

Charge Temperature

0ºC to 45ºC(32F to 113F)@60±25% Relative Humidity

Discharge Temperature

-20ºC to 60ºC(-4F to 140F)@60±25% Relative Humidity

Storage Temperature

0ºC to 40ºC(32F to 104F)@60±25% Relative Humidity

Water Dust Resistance

IP54

Cell&Method

1S

Package

PVC

Dimensions(in./mm.)

Diameter: 32mm; Height: 70mm

Weight(lbs./kg.)

145g



Product Images



Ifr32650 Ifr32700 6ah 3.2V Lifepo4 Battery Bms Cylindrical LiFePO4 Cell 0

Ifr32650 Ifr32700 6ah 3.2V Lifepo4 Battery Bms Cylindrical LiFePO4 Cell 1

Ifr32650 Ifr32700 6ah 3.2V Lifepo4 Battery Bms Cylindrical LiFePO4 Cell 2

Ifr32650 Ifr32700 6ah 3.2V Lifepo4 Battery Bms Cylindrical LiFePO4 Cell 3



Product Advantages


1. Professional technical team: WelsonPower’s R&D technical team has received more than 20 inventions and application patents.

2. Unique pack technique: WelsonPower possesses special pack technique to batter protect the battery cell and increase the life span of the battery pack.

3. Safety certification guarantee: Most batteries have been certificated according to international standard including CE, MSDS, UN38.3, UL etc..

4. Professional sales team: WelsonPower possess well-trained sale team that help clients addressing difficulty meeting during battery selecting and battery using.

5. Punctual delivery: WelsonPower has strict production plan to promise punctual delivery of the goods.

6. Perfect after-sales service: WelsonPower has a professional QC team which applies strict quality control on production and provide perfect after-sales service to clients.







Deep cycle/recycle lithium battery

We current main produce 18650/26650/21700/30700/4680 lithium ion cell and lithium iron phosphate cell,Lithium-ion batteries have a theoretical lifespan of about 800 cycles,and for lifepo4 cell,the cycle life around 1500-2000 times

Ifr32650 Ifr32700 6ah 3.2V Lifepo4 Battery Bms Cylindrical LiFePO4 Cell 4





BATTERY WITH PCM
The PCM main IC we used Japan Seiko IC,it has Over-charge,over-discharge,over-current and short-circuit Protection function.The PCM also can customized to your request,such as add PTC, NTC,and with cell balance function.

Ifr32650 Ifr32700 6ah 3.2V Lifepo4 Battery Bms Cylindrical LiFePO4 Cell 5







FINISHED BATTERY WITH PCM



Finished battery usually it is with PCM.Wire, and connector,it used for Bluetooth speaker, led light,solar street light and other digital device.





Ifr32650 Ifr32700 6ah 3.2V Lifepo4 Battery Bms Cylindrical LiFePO4 Cell 6





Applications

Ifr32650 Ifr32700 6ah 3.2V Lifepo4 Battery Bms Cylindrical LiFePO4 Cell 7

We Are Real Factory!!!

1 good quality, experience with famous brands

2 OEM service for customized battery

3 26650 cell(2000 times cycle 3 life.after 2000 tims,still keeps 80%of inital capacity

4 Our certification is complete

5 Sample order(<10 pcs) is available---helps you test the quality with "O"risk

6 12 month wanrranty---replace one by one if there is any quality problem

7 In the field of batteries Have more than 10 year professional experience





Production Line

Ifr32650 Ifr32700 6ah 3.2V Lifepo4 Battery Bms Cylindrical LiFePO4 Cell 8





Packaging & Shipping



Package:

With high quality pearl wool, UN cartons / Plywood, plastic pallet.



Shipping:



By air, by sea, by express, railway transportation and so on.



1. Shippment to USA:By sea+Express(DDP,Tax free)

ETD:5-8 days
ETA:25-35 days after sailing(This is the delivery time for most orders. Please wait patiently or contact us online)
The tracking will be updated after pick up by local express.Usually it will take around 15-25 days after sailing.



2. Shipment to EU:By railway+Express(DDP,Tax free).Except Switzerland,Romania


ETD:5-8 days
ETA:30-45 working days after shipping(This is the delivery time for most orders. Please wait patiently or contact us online)
The tracking will be updated after pick up by local express.Usually it will take around 25-40 working days after shipping.



3. We can't deliver the following address directly:


USA: Military address and PO box address are not acceptable;

Puerto Rico, Virgin Islands, Guam, Alaska Note: Hawaii does not include customs duties and requires additional freight, Please contact us online.
Portugal: Azores and Madeira
Spain:Canary Islands, hueda and melilia
Russia: Kamchatka Peninsula
Other:Some remote areas not listed,Please provide shipping address and zip code to to us to check.



FAQ



Q1: What is your MOQ?
A1: Generally speaking, our MOQ is 100 pieces, which varies with different products.


Q2: Are these batteries brand new?
A2: Yes, all of these batteries we provide are brand new


Q3: Are the cells I bought balanced?
A3: we know the importance of maintaining the consistency of each cell in the battery pack, so we will match and balance all cells to ensure that the internal resistance, voltage, and capacity of cells are completely matched and balanced before delivery. This process is very necessary.


Q4:: I am a distributor. Can I cooperate with the battery warehouse for a long time?
A4: Yes, Individual pricing for large scale projects and wholesale demand is available





About US

WelsonPower



Welson Battery Company, a world leader in deep cycle battery technology, has been at the forefront of superior deep cycle battery development since 2003. The Deep Cycle Flooded LFP Battery is specifically designed for use in golf carts, solar applications and more. Welson's decades of experience, ongoing research, and commitment to quality are evident in every deep cycle battery they produce.

The WelsonPower advantage lies in their ability to provide dependable, long-lasting, continuous power and exceptional value. This is true for every deep cycle battery with the distinct nice case. Although flooded lead-acid batteries have the longest history of use in solar electric applications and are still utilized in most stand-alone alternative energy systems, they do require regular maintenance in the form of watering, equalizing charges, and keeping the top and terminals clean, in order to reap the benefits of longer lifespan and lower cost per amp-hour.

Newest technology,new idea,heard-working and honest people.



Focus on lithium rechargeable battery,BMS,Balancer,charger and relative products.

Main application:electric bicycle,scooter,motorhome,AGV,solar/wind system,Energy storage system,truck and so on.s:

We promise"real"lithium capacity

We promise“100%“ refund for any quality problem

We promise”100%“ replacement for any shipping damage

We promise lifetime fast technical supportCustomers‘ satisfaction is our endless pursuing.
